SC-BL-M
9V~24V
| Color: | |
|---|---|
| Support: | |
| Voltage: | |
| Power: | |
| Size: | |
LED Bluetooth Mesh Controller for Dimmable RGB RGBW CCT Flexible LED Strip Lights
Introduction
For single color led strip, controller is an optional; For rgb led strip light, controller is a must to change colors and lighting modes. There's many different controller for led strip lights, including Mini Controller, IR Controller, RF Controller, RF Music Controller, Bluetooth Controller, WiFi Controller, Bluetooth Music Controller, and other LED Controller. Mini series bluetooth mesh controller is a kind of brand new smart controller. It uses the latest Bluetooth Mesh module and Bluetooth networking technology. Use low power consumption both-way communication Bluetooth mesh chip to make sure controller have longer distance. The latest APP interface design makes the operation of color adjustment, brightness adjustment and saturation adjustment easier, faster and more humanized. The main functions are brightness adjustment, timer, group, scene, call reminder and so on.This controller is with power off memory function, next time to used it, will start with the model it save. Mainly used to control all kinds of constant voltage led strip lights.
Product Features
It’s a series products contain: Dimming, CCT, RGB, RGBW, RGB+CCT 5 kinds of LED controllers
Adopt DC 12V-24V wide voltage, it support regular DC12V, DC24V LED strip lights
Use low power consumption both-way communication Bluetooth chip to make controller have longer distance
Auto-transmitting function: this Bluetooth mesh controller can transmit the signals between each other within 25 meters, mesh network make control distance limitless
Main functions: Timer, Group, Scene, Phone calling reminder etc
With 10% 20% 40% 60% 80% 100% 6 kinds of white color shortcut keys can be chosen quickly and easy
Can set any timer to turn on led strip, turn off led tape light, and set different lighting mode alarms
Specification
| Model No. | LED Strip Color | Specification | Dimension |
| SC-BL-M1 | Single Color | Votagle: 12V-24V Static Power: <1W 12V<72W 24V<144W | L58*W28*H11mm L95*W60*H18mm 45g |
| SC-BL-M2 | CCT Color | ||
| SC-BL-M3 | RGB Color | ||
| SC-BL-M4 | RGBW Color | ||
| SC-BL-M5 | RGB+CCT |
Instruction
1. Install power supply, controller and led strip light then power on, Open Bluetooth via mobile phone.
2. Search "OPEN-LIT" in APP Store or Google play→Turn on APP, click “Register”in the top right→Enter your email→Set your password→click “Register”.
3. After login, enter "Device" interface, Click “+” to add new device, then click “ Add Bluetooth device” to start configuration. Then APP will remind you if it complete the configuration within 40sec.
4. After the configuration, click “Back” and app will enter “Device” interface. Please click“ Continue to configure” if the configuration failed or you want to configure next device.
5. Open the “Device” interface, operate the lamp to start your intelligent life.
