24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
Introduction
COB LED Strip Lights, which called cob led ligt tape, is the newest innovation in 2019. It's high dentisy chips and prodvides a completely uniform light line without any light dot or dark area. Pure White, Warm White, Red, Green, Blue are both available for choice. If you use it with aluminum profile, you can choose 22w/m. If you use it without aluminum profile, 16w/m is recommended.
Product Features
No Dot or Light Spot
3oz Flexible PCB
3 Years Warranty
High CRI 80+
Fully Dimmable
180° Beam Angle
High Lumen Max 2000lm
3M Brand Adhesive Tape
Available Colors
Pure White COB LED Strip | Warm White COB LED Strip |
Red | Green | Blue |
Advantage
a. Invisible LED v.s Visible LED
b. 180° Beam Angle v.s 120° Beam Angle
c. 528chips/m 10mm PCB v.s 120LEDs/m 15mm PCB
Applications
Home Decorative Lighting
Cabinets and Shelving
Hotel Lobbies Lighting
Shop Display Lighting
Patio and Garden Lighting
Architectural Buidling Lighting
Why Choose Ledodm's led strip lights?
High Lumen Chip
Lumen parameter is the measurement of led strip light brightness. For cob led strip lights, the chip size is 10*30mm, you can compare the lumen output with others on the market. Doing so, you'll find that our LEDs carries the brightest lumen among led strips in their class.
3oz Flexible PCB
As for cob led light strip, the main key is chip and pcb. 3oz pcb thickness is better than 2oz and 1oz fleixble pcb, and it has good heat dissipation and long lifespan, that's why we can assure 3 years warranty for new product.
Professional in LED Strip
Ledodm is a preferred supplier for led tape light distributor, international lighting designers, building contractors and renowned architects from all over the world. We concern every development in led strip industry and pay close attention to every innovation, and we want share our knowledge and passion with as many people as possible. Our specialists are here to assist in your project’s development from imagination to realization.
24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
Introduction
COB LED Strip Lights, which called cob led ligt tape, is the newest innovation in 2019. It's high dentisy chips and prodvides a completely uniform light line without any light dot or dark area. Pure White, Warm White, Red, Green, Blue are both available for choice. If you use it with aluminum profile, you can choose 22w/m. If you use it without aluminum profile, 16w/m is recommended.
Product Features
No Dot or Light Spot
3oz Flexible PCB
3 Years Warranty
High CRI 80+
Fully Dimmable
180° Beam Angle
High Lumen Max 2000lm
3M Brand Adhesive Tape
Available Colors
Pure White COB LED Strip | Warm White COB LED Strip |
Red | Green | Blue |
Advantage
a. Invisible LED v.s Visible LED
b. 180° Beam Angle v.s 120° Beam Angle
c. 528chips/m 10mm PCB v.s 120LEDs/m 15mm PCB
Applications
Home Decorative Lighting
Cabinets and Shelving
Hotel Lobbies Lighting
Shop Display Lighting
Patio and Garden Lighting
Architectural Buidling Lighting
Why Choose Ledodm's led strip lights?
High Lumen Chip
Lumen parameter is the measurement of led strip light brightness. For cob led strip lights, the chip size is 10*30mm, you can compare the lumen output with others on the market. Doing so, you'll find that our LEDs carries the brightest lumen among led strips in their class.
3oz Flexible PCB
As for cob led light strip, the main key is chip and pcb. 3oz pcb thickness is better than 2oz and 1oz fleixble pcb, and it has good heat dissipation and long lifespan, that's why we can assure 3 years warranty for new product.
Professional in LED Strip
Ledodm is a preferred supplier for led tape light distributor, international lighting designers, building contractors and renowned architects from all over the world. We concern every development in led strip industry and pay close attention to every innovation, and we want share our knowledge and passion with as many people as possible. Our specialists are here to assist in your project’s development from imagination to realization.
24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
Completely smooth and even light spread
High density 528chips/m led strip lights
Long lifespan, more than 50000hours
3oz Flexible PCB, better heat dissipation
Widely used for indoor and outdoor lighting
Model No. | QTY/M | Voltage | PCB Width | Color | Lumen/M | Power/M | CRI |
SL-COB-528PW | 528Chips/m | 24V | 10mm | 6000-6500K | 2000LM | 16W | 80 / 90 |
SL-COB-528WW | 528Chips/m | 24V | 10mm | 2700-3200K | 1800LM | 16W | 80 / 90 |
SL-COB-528RL | 528Chips/m | 24V | 10mm | Red | 500LM | 16W | 80 / 90 |
SL-COB-528GL | 528Chips/m | 24V | 10mm | Green | 2200LM | 16W | 80 / 90 |
SL-COB-528BL | 528Chips/m | 24V | 10mm | Blue | 400LM | 16W | 80 / 90 |
24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
Completely smooth and even light spread
High density 528chips/m led strip lights
Long lifespan, more than 50000hours
3oz Flexible PCB, better heat dissipation
Widely used for indoor and outdoor lighting
Model No. | QTY/M | Voltage | PCB Width | Color | Lumen/M | Power/M | CRI |
SL-COB-528PW | 528Chips/m | 24V | 10mm | 6000-6500K | 2000LM | 16W | 80 / 90 |
SL-COB-528WW | 528Chips/m | 24V | 10mm | 2700-3200K | 1800LM | 16W | 80 / 90 |
SL-COB-528RL | 528Chips/m | 24V | 10mm | Red | 500LM | 16W | 80 / 90 |
SL-COB-528GL | 528Chips/m | 24V | 10mm | Green | 2200LM | 16W | 80 / 90 |
SL-COB-528BL | 528Chips/m | 24V | 10mm | Blue | 400LM | 16W | 80 / 90 |
24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
End Wire for FOB LED Strip Light
Black and Red Wire | SM Male Femal Connector | DC Male Femal Connector |
Connector for 10mm LED Strip Light
2Pin Connector | 2Pin Connector with 150mm Wire | 2Pin Double Head Connector (150mm) |
L Connector | T Connector | X Connector |
24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
End Wire for FOB LED Strip Light
Black and Red Wire | SM Male Femal Connector | DC Male Femal Connector |
Connector for 10mm LED Strip Light
2Pin Connector | 2Pin Connector with 150mm Wire | 2Pin Double Head Connector (150mm) |
L Connector | T Connector | X Connector |
24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
FOB LED Strip Light FAQ:
Q: What is the cob led tape light?
Cob led strip lights is very diffrent from smd led strip, you canot see visible led when it's light on, there's no necessary to use plastic cover to make invisible led.
Q: What is the product lifespan?
Our led tape lights have been strictly tested and have an expected lifespan of 50,000hours before dropping to 70% luminosity. It means using 12hours per day, the lights would last more than 10 years.
Q: What is color temperature?
Most white lights fall in a spectrum between 1800K and 6500K, measured in Kelvins (K). When dropping below 3000K, the light is noticeably warmer. When rising above 6500K, the lights have a blue-ish tint and cooler tone.
Q: What is product lumen?
This is one way we can measure light output, the more lumen, the higher brightness. For 5050 smd led, we have 16-18lm, 18-20lm, 20-22lm and 22-24lm for led strip lights.
Q: What does IP meam?
This is a rating system that defines the ability of led strip to be able to work in different environments. It is a measurement of the protection an item will have against solid objects and liquids. An IP rating is comprised of 2 numbers, the first one refers to the protection against solid objects and the second one refers to protection against liquids.
Q: What is CRI?
Color Rendering Index (CRI) is the measurement of how colors look under a light source when compared with sunlight. The index is measured from 0-100, with a perfect 100 indicating that colors under the light source appear the same as they would under natural sunlight.
More Information on LED Strip Lights:
90% of our customers found this page useful in selecting their LED strips
24V High Brightness Flexible COB LED Strip Green Tape Light for Aluminum Profile
FOB LED Strip Light FAQ:
Q: What is the cob led tape light?
Cob led strip lights is very diffrent from smd led strip, you canot see visible led when it's light on, there's no necessary to use plastic cover to make invisible led.
Q: What is the product lifespan?
Our led tape lights have been strictly tested and have an expected lifespan of 50,000hours before dropping to 70% luminosity. It means using 12hours per day, the lights would last more than 10 years.
Q: What is color temperature?
Most white lights fall in a spectrum between 1800K and 6500K, measured in Kelvins (K). When dropping below 3000K, the light is noticeably warmer. When rising above 6500K, the lights have a blue-ish tint and cooler tone.
Q: What is product lumen?
This is one way we can measure light output, the more lumen, the higher brightness. For 5050 smd led, we have 16-18lm, 18-20lm, 20-22lm and 22-24lm for led strip lights.
Q: What does IP meam?
This is a rating system that defines the ability of led strip to be able to work in different environments. It is a measurement of the protection an item will have against solid objects and liquids. An IP rating is comprised of 2 numbers, the first one refers to the protection against solid objects and the second one refers to protection against liquids.
Q: What is CRI?
Color Rendering Index (CRI) is the measurement of how colors look under a light source when compared with sunlight. The index is measured from 0-100, with a perfect 100 indicating that colors under the light source appear the same as they would under natural sunlight.
More Information on LED Strip Lights:
90% of our customers found this page useful in selecting their LED strips
