Side Emitting View SMD 3014 Flexible LED Strip Light 120LEDs/m

  • SL-3014-120SE

  • SMD3014

  • 120LEDs/m

  • 8mm

  • 12W/m

Voltage:
Color:
CRI:
IP Rating:
Availability:

Side Emitting View SMD 3014 Flexible LED Strip Light 120LEDs/m


side view 3014 led strip dimension

Introduction

Side emitting led strip light, sometimes referred as "side view led tape light", is designed with side-emitting led, like smd3014, smd335 and smd315. SMD 3014 has high lumen 10-12lm per LED, much more brightness than SMD 335 and SMD315. With reliable chip, SMD3014 led strip light has high brightness, excellent heat dissipation and uniform luminance, which is a perfect selection to meet the demands of indoor lighting design and innovative lighting projects. With a dimming controller, you can use it in different applications, from high brightness to comfortable accents.


Product Features

  • 3 Years Warranty

  • High CRI 80+ 90+

  • Fully Dimmable

  • 120° Beam Angle

  • Single Bin LED Availble

  • 3M Brand Adhesive Tape


Available Colors

5050 led strip color


Applications

  • Home Decorative Lighting

  • Cabinets and Shelving

  • Hotel Lobbies Lighting

  • Shop Display Lighting

  • Patio and Garden Lighting

  • Architectural Buidling Lighting

  • Narrow Space Lighting


Why Choose Ledodm's led strip lights?

  • High Lumen LED

    Lumen parameter is the measurement of led strip light brightness. You can compare the lumen output with others on the market. Doing so, you'll find that our LEDs carries the brightest lumen among led strips in their class.

  • Guaranteed Performance

    Produced with high quality led chip, pcb and resistor, led strips can be used for many high end projects and OEM products. After testing, our led strip light will dim to 70% of original brightness after using for 50,000 hours.

  • Professional in LED Strip

    Ledodm is a preferred supplier for led strip light distributor, international lighting designers, building contractors and renowned architects from all over the world. We concern every development in led strip industry and pay close attention to every innovation, and we want share our knowledge and passion with as many people as possible. Our specialists are here to assist in your project’s development from imagination to realization.

Side Emitting View SMD 3014 Flexible LED Strip Light 120LEDs/m


  • Epistar Chip & Brand LED

  • 2oz or 3oz Flexible Double-sided PCB

  • 12V 3LEDs Cuttable, 24V 6LEDs Cuttable

  • IP65 Silicone Glue Waterproof (Not PU Glue)

Model No. LED Type QTY/M Voltage PCB Width Color Temp IP Rating Power/M CRI
SL-3014-120SPW1 SMD3014 120LEDs DC 12V 24V 8mm 6000-6500K IP20 14.4W 80 / 90
SL-3014-120SPW2 SMD3014 120LEDs DC 12V 24V 8mm 6000-6500K IP65 14.4W 80 / 90
SL-3014-120SPW3 SMD3014 120LEDs DC 12V 24V 8mm 6000-6500K IP66 14.4W 80 / 90
SL-3014-120SPW4 SMD3014 120LEDs DC 12V 24V 8mm 6000-6500K IP68 14.4W 80 / 90
SL-3014-120SNW1 SMD3014 120LEDs DC 12V 24V 8mm 4000-4500K IP20 14.4W 80 / 90
SL-3014-120SNW2 SMD3014 120LEDs DC 12V 24V 8mm 4000-4500K IP65 14.4W 80 / 90
SL-3014-120SNW3 SMD3014 120LEDs DC 12V 24V 8mm 4000-4500K IP66 14.4W 80 / 90
SL-3014-120SPW4 SMD3014 120LEDs DC 12V 24V 8mm 4000-4500K IP68 14.4W 80 / 90
SL-3014-120SWW1 SMD3014 120LEDs DC 12V 24V 8mm 2700-3200K IP20 14.4W 80 / 90
SL-3014-120SWW2 SMD3014 120LEDs DC 12V 24V 8mm 2700-3200K IP65 14.4W 80 / 90
SL-3014-120SWW3 SMD3014 120LEDs DC 12V 24V 8mm 2700-3200K IP66 14.4W 80 / 90
SL-3014-120SWW4 SMD3014 120LEDs DC 12V 24V 8mm 2700-3200K IP68 14.4W 80 / 90


Side Emitting View SMD 3014 Flexible LED Strip Light 120LEDs/m


End Wire for 3014 LED Strip Light

red and black wire for led strip

Black and Red Wire


sm male female connector for led strip

SM Male Femal Connector


dc connector for led strip light

DC Male Femal Connector



Connector for LED Strip Light

connector for ip20 led strip

2Pin Connector


connector for 5050 led strip

2Pin Connector with 150mm Wire


connector for two led strip light

2Pin Double Head Connector (150mm)

L Connector for led strip light

L Connector


T Connector for led strip light

T Connector


x connector for led strip light

X Connector


Side Emitting View SMD 3014 Flexible LED Strip Light 120LEDs/m


SMD3014 LED Strip Light FAQ:


  • Q: What is the product warranty?

    The warranty on led strip lights ranges from 2 to 5 years which depends on the product material requested.


  • Q: What is the product lifespan?

    Our led tape lights have been strictly tested and have an expected lifespan of 50,000hours before dropping to 70% luminosity. It means using 12hours per day, the lights would last more than 10 years.


  • Q: What is color temperature?

    Most white lights fall in a spectrum between 1800K and 6500K, measured in Kelvins (K). When dropping below 3000K, the light is noticeably warmer. When rising above 6500K, the lights have a blue-ish tint and cooler tone.


  • Q: What is product lumen?

    This is one way we can measure light output, the more lumen, the higher brightness. For 5050 smd led, we have 16-18lm, 18-20lm, 20-22lm and 22-24lm for led strip lights.


  • Q: What does IP meam?

    This is a rating system that defines the ability of led strip to be able to work in different environments. It is a measurement of the protection an item will have against solid objects and liquids. An IP rating is comprised of 2 numbers, the first one refers to the protection against solid objects and the second one refers to protection against liquids.


  • Q: What is CRI?

    Color Rendering Index (CRI) is the measurement of how colors look under a light source when compared with sunlight. The index is measured from 0-100, with a perfect 100 indicating that colors under the light source appear the same as they would under natural sunlight.
